Power Supply/Motor Power 110V/220V/380V 1.1/0.75kw
Pneumatic supply 0.8-1.2MPa
Rim Clamping Range (External) 13"-24"
Rim Clamping Range (internal) 15"-26"
Bead Loosening Force 2500kg
Max. Wheel Diameter 1100mm
Max. Wheel Width 15"
Noise <70Db
N.W./G.w. 335kg/436kg

Suitable for 13"-26" stiff, wide and low-profile.
With self-centering function.
Clamping system with stepping function.
With quick inflation for tubeless tyres.
Articulated mount arm.
Air reserve tank.
Robotic arm (Optional)
With adjusting & calibrating functions in the 4 clamps on the turntable.
Rubber-pad mount/demount head.
Angles of mount/demount head can be adjusted and calibrated.
Polymer mount/demount head of high quality prevent damage to the rim.
